Condition Wiring Supply LED Buzzer
Number Condition Terminal Display
N E L
Socket Wiring
1 Correct N E L Continuous
2 L-E reverse N L E Warble
3 L-N-E miswire E L N Warble
4 L-N reverse L E N Warble
5 L-N-E miswire L N E Warble
6 Faulty N / L-E miswire NC L N Warble
7 Faulty N / E miswire NC N L Warble
8 Faulty N NC E L Warble
9 Faulty N / L-E reverse NC L E Warble
10 Faulty E / L-N reverse L NC N Warble
11 Faulty E N NC L Warble
12 Faulty E / N miswire E NC L Warble
13 Faulty E / L-N miswire L NC E Warble
14 Faulty L / N-E miswire L N NC Warble
15 Faulty L / E miswire N L NC Warble
16 Faulty L / N-E miswire E L NC Warble
17 Faulty L / N miswire L E NC Warble
18 No Mains NC NC NC None
Above is the indication given when touching the touch pad.
LEDs will flash to indicate fault condition NC = No Connection
