Keysight Technologies E36231A User Manual

2 Verification and Adjustments
66 Keysight E36200 Series Service Guide
Table 2-5 CV ripple and noise, peak-to-peak instrument settings
Model
DUT settings Fixed load RMS noise
Voltage (V) Current (A) Value (W) Lower limit Upper limit
E36231A /
E36233A
30 MAX 4.5 - 4.5 mV
10 MAX 0.5 - 4.5 mV
E36232A /
E36234A
60 MAX 18 - 3.5 mV
20 MAX 2 - 3.5 mV
Table 2-6 CV ripple and noise, rms instrument settings
Model
DUT settings Fixed load Peak-to-peak noise
Voltage (V) Current (A) Value (W) Lower limit Upper limit
E36231A /
E36233A
30 MAX 4.5 - 0.35 mV
10 MAX 0.5 - 0.35 mV
E36232A /
E36234A
60 MAX 18 - 0.35 mV
20 MAX 2 - 0.35 mV
