1 General Information
16 Series E4360 User’s Guide
Front Panel Menu Reference
NOTE
Menu commands that are grayed-out are password protected.
Menu Command Control Description
Output
Fixed
Voltage
Programs the output voltage in Fixed mode
Current
Programs the output current in Fixed mode
SAS
Curve
Programs the SAS curve parameters (Vmp, Voc, Imp, Isc).
Source
Selects the source of the curve parameters (Immediate, List)
Table
Select table
Programs the SAS curve parameters from the selected table.
Mode
Selects the operating mode (Fixed, SAS, Table).
Resolution
Specifies curve resolution in SAS & Table mode: Low or High.
Couple
Couples output channels for output on/off synchronization.
Acquisition
Control
Displays trigger delay, source, and state. Aborts measurements.
Transient
List
Pace
Specifies Dwell or Trigger paced list.
Count
Specifies number of list repetitions, or specifies continuous list.
Terminate
Specifies list settings when the list terminates.
Config
Configures a list of Vmp, Voc, Imp, Isc, and Dwell signals.
Reset
Aborts the list and resets all list parameters.
TrigSource
Specify the trigger source: Bus, Pin 1-7, Tran or Dwell output.
Control
Initiates, triggers, or aborts a transient. Displays trigger state.
Protect
OVP
Configures over-voltage protection function.
OCP
Configures over-current protection function.
SoftLimits
Voltage
Specifies the high limit for the output voltage setting
Current
Specifies the high limit for the output current setting
Inhibit
Configures the external inhibit signal: Off, Latching.
Coupling
Disables ALL output channels when a protection fault occurs.
Clear
Clears output protection. Displays output state.
System
IO
LAN
ActiveSettings
Displays the LAN interface settings that are presently active.
Config IP Configures the IP addressing of the instrument.
Name Configures the Dynamic DNS and NetBIOS naming service.
Domain Configures the Domain Name.
DNS Configures the DNS server.
TCP Configures the TCP keepalive function.
Reset Resets the LAN interface settings to the factory-shipped state.
USB
Status
Displays status, speed, packets received, and packets sent.
Identification USB connect string – the instrument’s unique USB identifier.
GPIB
Selects the GPIB address.
DigPort
Pin1
Function
Polarity
Specifies pin function: DigIn, DigIO, FaultOut.
Specifies pin polarity: Positive, Negative
Pin2
Function
Polarity
Specifies pin function: DigIn, DigIO,
Specifies pin polarity: Positive, Negative
