Installation
General Information.................................................................... 20
Inspecting the Unit ..................................................................... 21
Installing the Unit ....................................................................... 21
AC Line Connection .................................................................... 26
Rear Panel Connectors ............................................................... 26
Load Connections ....................................................................... 28
Remote Voltage Sensing ............................................................ 31
Connecting Outputs in Parallel .................................................. 33
Connecting Outputs in Series..................................................... 37
Analog Current Control .............................................................. 38
T
his chapter describes how to install your SAS. It discusses rack
mounting and line cord connections.
This chapter also discusses how to connect your load to the output
terminals. It discusses what you need to know about wire sizes and how
to compensate for voltage drops in the load leads. It describes various
loads configurations and how to connect the output terminals in series
and parallel.
Before installing the instrument, check the list under “Items Supplied”
and verify that you have received these items with your instrument. If
anything is missing, please contact your nearest Keysight Sales and
Support Office.
