Record A31 Motherboard Version Number (For Instruments with Serial Prefixes
<US4805/MY4805)
1. Press Utility > Instrument Info/Help Mode > Installed board info.
2. Find the information for the Motherboard.
3. Write down the version number of the Motherboard.
Check Firmware Version and Upgrade if < C.04.23
1. Press Utility > Instrument Info/Help Mode > Diagnostic Info.
2. Find the firmware information.
3. If the version of firmware is <C.04.23, upgrade the firmware.
Update the Arrays if Serial Number Prefix is < US/MY 4805
1. Connect the instrument to a LAN and write down the IP address.
Press
Utility > Instrument Info/Help Mode > Diagnostic.
2. Load the IP address into the instrument.
Press
Utility > GPIB/RS-232/LAN > LAN Setup > IP Address. Enter the IP address.
3. Using the web browser on the PC, enter the following URL, replacing <ip-address> with the actual IP address you
entered into the instrument in the previous step.
Type: http://<ip-address>/update.
4. Copy the script below and paste it into the text area on the System Update page shown in Figure 1.
Figure 1 System Update Web Page
