332 Keysight N9927-90001 User’s Guide
5G Rapid Prototype Phased Array Antenna – Option 360
About Phased Array Antenna Measurements
About Phased Array Antenna Measurements
Some measurement parameters are auto-coupled and are not user-settable.
Phased Array Antenna Features (Option 360)
Phased array antenna has the following features:
Scan Results:
— 28 GHz operation
— gNB RF parametric test over-the-air in the field
— Measure EIRP (effective isotropic radiated power)
— Milli-meter wave beam sweep survey with map
— Support for real-time spectrum analysis, transmitter power and spectrum
emission mask (SEM)
Data Formats:
User can set up and display the following:
— Bore-Sight – Elevation angle is fixed. Scan azimuth –60 degrees to +60
degrees.
— Heat Map – Scan both elevation and azimuth angle with adjustable color
"heat" amplitude scale.
— Polar ANT – Scan azimuth angle. Elevation is fixed.
— Park ANT – Polar image overlay load image:
—Resize polar coordinates
— Specify alignment angles
— Specify compass true north
— Define antenna direction (azimuth degrees)
IMPORTANT! Option 360 antenna requires a static IP address. If it is
required to have available an IP address that can be accessed over your
company’s network, work with your company’s IT team to set up a static IP
that works over the network.
IMPORTANT! If you forget you N9910X-028 Ball Antenna’s static IP
address, refer to this link and the Support tab for assistance:
www.keysight.com/find/fieldfox and then to the Phase Array Antenna
Support Document.
