Keysight N9927-90001 User’s Guide 349
5G Rapid Prototype Phased Array Antenna – Option 360
How to Set Up Phased Array Antenna Settings
Learn more, refer to Chapter 9, “SA (Spectrum Analyzer) Mode.”
— Restart
14. Optional: choose devices and save files:
Press Save/Recall
Then choose:
— Save
to set the attenuator power (default: –10 dB). Set to 0 dB.
— Recall
change to ON.
— Device
to set the absolute power (dBm)
— File Type
then choose:
— State
Saves the current state settings
— Trace+State
Saves the current Trace+State information
— Picture (PNG)
to save the current displayed trace as a PNG
— Data (CSV)
save files as a CSV file
Learn more, refer to Chapter 31, “File Management.”
15. Optional: Modify scale and amplitude values:
Press Scale/Amptd
Then one of the following:
— Autoscale
Automatically adjusts the Y-axis minimum and maximum
values.
— Scale
Manually enter a scale per division values.
— Others: Scale
, Ref Level, etcetera as desired.
Learn more, refer to Chapter 28, “Data Analysis Features.”
16. Optional: Modify the averaging and Integrated BW settings:
Press BW
Then one of the following:
— Average Enable OFF ON
— Average Count
— Integ BW
Learn more, refer to Chapter 28, “Data Analysis Features” and Chapter 9,
“SA (Spectrum Analyzer) Mode.”
