10 | Keysight | FieldFox Handheld Analyzers - Configuration Guide
Step 1. Select the model that provides the desired frequency range.
Model Description Frequency Test port connectors
N9925A 9 GHz FieldFox microwave VNA 30 kHz to 9 GHz Type-N (f)
N9926A 14 GHz FieldFox microwave VNA 30 kHz to 14 GHz Type-N (f)
N9927A 18 GHz FieldFox microwave VNA 30 kHz to 18 GHz Type-N (f)
N9928A 26.5 GHz FieldFox microwave VNA 30 kHz to 26.5 GHz 3.5 mm (m)
A standard N992xA FieldFox microwave VNA includes transmission/reflection measurement capability. Additional functionality such as
full 2-port S-parameters can be added using the options listed below.
Step 2. Select optional measurement capabilities.
Any of these options can easily be added as a software upgrade in the future.
FieldFox microwave vector network analyzer options
FieldFox Microwave Vector Network Analyzers
FieldFox microwave vector network analyzer models
Option Description Prerequisite options/notes
Vector network analysis / CAT
010 VNA time domain Recommend 211
112 QuickCal See page 11, FAQ #7
211 VNA full 2-port S-parameters -
212 1-port mixed-mode S-parameters Requires 211
215 TDR cable measurements Requires 305
305 Cable and antenna analyzer -
308 Vector voltmeter 211 required to obtain full VVM functionality. See page 11, FAQ #5
Power measurements
208 USB power sensor meas. versus frequency Requires 302
302 USB power sensor support Need to order USB power sensor
1
310 Built-in power meter No power sensor required. See page 8, FAQ #1
330 Pulse meas. with USB peak power sensor Need to order USB peak power sensor. See page 9, FAQs #7 and #8
System features
030 Remote control capability Requires an iOS device
307 GPS receiver Need to order GPS antenna, N9910X-825. See page 9, FAQ #3
309 DC bias variable-voltage source -
1. List of compatible sensors available from www.keysight.com/find/fieldfoxsupport
