16 | Keysight | FieldFox Handheld Analyzers - Configuration Guide
Calibration Kits
Model Description Connector Frequency range Components
1
7-16
N9910X-802 3-in-1 OSL cal kit 7/16 (m) DC to 4 GHz open, short, load (all male)
N9910X-803 3-in-1 OSL cal kit 7/16 (f) DC to 4 GHz open, short, load (all female)
85038A Standard cal kit 7/16 DC to 7.5 GHz open, short, load (both female and male)
Type-N, 50 Ω
N9910X-800 3-in-1 OSL cal kit Type-N (m) DC to 6 GHz open, short, load (all male)
N9910X-801 3-in-1 OSL cal kit Type-N (f) DC to 6 GHz open, short, load (all female)
85032E Economy cal kit Type-N (m) DC to 6 GHz open, short, load (all male)
85514A 4-in-1 OSLT cal kit Type-N (m) DC to 9 GHz open, short, load, thru (all male)
85515A 4-in-1 OSLT cal kit Type-N (f) DC to 9 GHz open, short, load, thru (all female)
85032F Standard cal kit Type-N DC to 9 GHz open, short, load (both female and male)
85518A 4-in-1 OSLT cal kit Type-N (m) DC to 18 GHz open, short, load, thru (all male)
85519A 4-in-1 OSLT cal kit Type-N (f) DC to 18 GHz open, short, load, thru (all female)
85054D Economy cal kit Type-N DC to 18 GHz open, short, load, thru (both female and male)
85054B Standard cal kit Type-N DC to 18 GHz open, short, fixed load, sliding load (both female and male)
85092C ECal, 2-ports Type-N 300 kHz to 9 GHz connectors configurable
N4690B/C ECal, 2-ports Type-N 300 kHz to 18 GHz connectors configurable
N7550A ECal economy, 2-ports Type-N DC to 4 GHz connectors configurable
N7551A ECal economy, 2-ports Type-N DC to 6.5 GHz connectors configurable
N7552A ECal economy, 2-ports Type-N DC to 9 GHz connectors configurable
N7553A ECal economy, 2-ports Type-N DC to 14 GHz connectors configurable
N7554A ECal economy, 2-ports Type-N DC to 18 GHz connectors configurable
Type-N, 75 Ω
2
85036B Standard cal kit Type-N 75 Ω DC to 3 GHz open, short, load (both female and male)
85036E Economy cal kit Type-N(m) 75 Ω DC to 3 GHz open, short, load, all male
85096C ECal, 2-ports Type-N(m) 75 Ω 300 kHz to 3 GHz connectors configurable
3.5 mm
85520A 4-in-1 OSLT 3.5 mm (m) DC to 26.5 GHz open, short, load, thru (all male)
85521A 4-in-1 OSLT 3.4 mm (f) DC to 26.5 GHz open, short, load, thru (all female)
85033D/E Economy cal kit 3.5 mm DC to 6/9 GHz open, short, fixed load (both female and male)
85052D Economy cal kit 3.5 mm DC to 26.5 GHz open, short, fixed load (both female and male)
85052B Standard cal kit 3.5 mm DC to 26.5 GHz open, short, fixed load, sliding load (both female and male)
85052C Precision TRL kit 3.5 mm DC to 26.5 GHz open, short, fixed load (both female and male), two line lengths
85093C ECal, 2-ports 3.5 mm 300 kHz to 9 GHz connectors configurable
N4691B ECal, 2-ports 3.5 mm 300 kHz to 26.5 GHz connectors configurable
N7550A ECal economy, 2-ports 3.5 mm DC to 4 GHz connectors configurable
N7551A ECal economy, 2-ports 3.5 mm DC to 6.5 GHz connectors configurable
N7552A ECal economy, 2-ports 3.5 mm DC to 9 GHz connectors configurable
N7553A ECal economy, 2-ports 3.5 mm DC to 14 GHz connectors configurable
N7554A ECal economy, 2-ports 3.5 mm DC to 18 GHz connectors configurable
N7555A ECal economy, 2-ports 3.5 mm DC to 26.5 GHz connectors configurable
2.92 mm (same as K connector)
85561A 4-in-1 OSLT cal kit 2.92 mm (f) DC to 40 GHz open, short, fixed load, thru (all female)
85562A 4-in-1 OSLT cal kit 2.92 mm (m) DC to 40 GHz open, short, fixed load, thru (all male)
85056KE01
3
Standard cal kit 2.92 mm DC to 40 GHz open, short, fixed load, sliding load (both female and male)
85056KE02
4
Economy cal kit 2.92 mm DC to 40 GHz open, short, fixed load (both female and male)
N4692A ECal 2.92 mm 10 MHz to 40 GHz connectors configurable
1. Component list shows calibration components. Some cal kits also include adapters.
2. Recommend ordering quantity 2 of N9910X Option 846, 50 to 75 Ω adapter.
3. Same as Maury’s 8770C47
4. Same as Maury’s 8770D47
FieldFox analyzers support most standard HP/Agilent/Keysight mechanical calibration kits and all Keysight USB ECal modules.
Custom calibration kits can be created and uploaded to FieldFox using Data Link software.
