17 | Keysight | FieldFox Handheld Analyzers - Configuration Guide
Calibration Kits (continued)
Model Description Connector Frequency range Components
2.4 mm
85563A 3-in-1 OSL cal kit 2.4 mm (f) DC to 50 GHz open, short, fixed load (all female)
85564A 3-in-1 OSL cal kit 2.4 mm (m) DC to 50 GHz open, short, fixed load (all male)
85056D Economy cal kit 2.4 mm DC to 50 GHz open, short, fixed load (both female and male)
85056A Standard cal kit 2.4 mm DC to 50 GHz open, short, load, fixed load, sliding load (both female and male)
N4693A ECal 2.4 mm 10 MHz to 50 GHz connectors configurable
Waveguide
N9911X-11x Econ. waveguide cal kit WR-137 5.38 to 8.18 GHz short, termination, offset length
N9911X-21x Econ. waveguide cal kit WR-90 8.2 to 12.5 GHz short, termination, offset length
N9911X-31x Econ. waveguide cal kit WR-62 11.9 to 18 GHz short, termination, offset length
N9911X-41x Econ. waveguide cal kit WR-42 17.6 to 26.7 GHz short, termination, offset length
X11644A Waveguide cal kit WR-90 8.2 to 12.4 GHz short, shim, termination, standard section
P11644A Waveguide cal kit WR-62 12.4 to 18 GHz short, shim, termination, standard section
K11644A Waveguide cal kit WR-42 18 to 26.5 GHz short, shim, termination, standard section
R11644A Waveguide cal kit WR-28 26.5 to 40 GHz short, shim, termination two straight sections
Q11644A Waveguide cal kit WR-22 33 to 50 GHz short, shim, termination, two straight sections
U11644A Waveguide cal kit WR-19 40 to 60 GHz short, shim, termination, two straight sections
FieldFox analyzers support most standard HP/Agilent/Keysight mechanical calibration kits and all Keysight USB ECal modules.
Custom calibration kits can be created and uploaded to FieldFox using Data Link software.
