Keysight Technologies PNA-L N5230A

31
For devices with Type-N connectors
Mechanical calibration kits
– 85054B Standard: DC to 18 GHz.
Includes:
00909-60011 Type-N (m) fixed lowband load
00909-60012 Type-N (f) fixed lowband load
85054-60025 Type-N (m) short
85054-60026 Type-N (f) short
85054-60027 Type-N (m) open
85054-60028 Type-N (f) open
85054-60031 Type-N (f) to 7mm adapter
85054-60032 Type-N (m) to 7mm adapter
85054-60037 Type-N (f) to Type-N (f) adapter
85054-60038 Type-N (m) to Type-N (m) adapter
85054-80010 Type-N (f) sliding load
85054-80009 Type-N (m) sliding load
85054-60050 Type-N (f) connector gage
85054-60052 Type-N (f) gage master
85054-60051 Type-N (m) connector gage
85054-60053 Type-N (m) gage master
– 85054D Economy: DC to 18 GHz.
Includes:
85054-60025 Type-N (m) short
85054-60026 Type-N (f) short
85054-60027 Type-N (m) open
85054-60028 Type-N (f) open
85054-60031 Type-N (f) to 7mm adapter
85054-60032 Type-N (m) to 7mm adapter
85054-60037 Type-N (f) to Type-N (f) adapter
85054-60038 Type-N (m) to Type-N (m) adapter
85054-60046 Type-N (m) fixed load
85054-60047 Type-N (f) fixed load
Electronic calibration kits
– N4431B Microwave ECal: 300 kHz to 13.5 GHz, 4 ports.
Includes:
Option 020 module with:
N4431-60007 4 x Type-N (f) ECal module
N4431B-xxx mixed-connector options:
Connector type Port A
option
Port B
option
Port C
option
Port D
option
3.5 mm (f) 101 201 301 401
3.5 mm (m) 102 202 302 402
Type-N 50 ohm
(f)
103 203 303 403
Type-N 50 ohm
(m)
104 204 304 404
7-16 (f )
1
105 205 305 405
7-16 (m)
1
106 206 306 406
– N4432A Microwave ECal: 300 kHz to 18 GHz, 4 ports.
Includes:
Option 020 module with:
N4432-60003 4 x Type-N (f) ECal module
– N4432A-xxx mixed-connector options:
Connector type Port A
option
Port B
option
Port C
option
Port D
option
3.5 mm (f) 101 201 301 401
3.5 mm (m) 102 202 302 402
Type-N 50 ohm
(f)
103 203 303 403
Type-N 50 ohm
(m)
104 204 304 404
– N4690B Microwave ECal: 300 kHz to 18 GHz, 2 ports.
Includes:
Option M0F module with:
N4690-60001 Type-N (f) to Type-N (m) ECal module
Option 00M module with:
N4690-60002 Type-N (m) to Type-N (m) ECal module
Option 00F module with:
N4690-60003 Type-N (f) to Type-N (f) ECal module
Option 00A adds:
85054-60037 Type-N (f) to Type-N (f) adapter
85054-60038 Type-N (m) to Type-N (m) adapter
Cables
2
Use the test port cables recommended for devices with
7 mm connectors, and 7 mm to Type-N adapters that
are from the 85054B/D Type-N calibration kit (see 7 mm
connector section).
1. Limits ECal module high frequency to 7.5 GHz.
2. Special rugged female connector specically for connecting to the network analyzer
test port, but does not mate with a standard male connector.
