Performance Verification
IMPORTANT
At low power levels, residual spurs from adjacent instrument can cause the
DUT to fail the test. Therefore, the instrument must be adequately
separated from one another. Do not place one device on top of another. If
the test fails at very low power levels, offset frequency by +500 Hz and re-
test. This will shift the test frequency away from possible residual
responses.
Table 2 Test Equipment
Instrument
Critical Specifications 
(for this test)
Recommended Model(s)
Power Meter None Keysight E4419A or E
4419B
Power Sensor None Keysight E9304A (9 kHz to 6.0 GHz)
Keysight E9304A Option H19
(9 kHz to 18 GHz) E8257D Option 520
Microwave Amplifier 20 dB of Gain
(minimum)
Keysight 83006A (0.01 GHz to 26.5 GHz)
Power Supply Keysight 87421A
Spectrum Analyzer Displayed Average
Noise
E4440A, Option 1DS
E4443A, Option 1DS
E4445A, Option 1DS
E4446A, Option 1DS
E4448A, Option 1DS
3
