Keysight N5262BW Series User Manual

Keysight Technologies N5262BW/BT/BR/DRxx Mini VNAX Frequency Extension Modules
-
Table 7 Available TxRx Cable Sets
Keysight Cable
Option
a
VDI
Part Number
Description
501 C
S-TST-TxRx-1.2
1.2m cable set for controller
505 CS-TST-TxRx-5
5m cable set for controller
201 CS-24-TxRx-1.2 1.2m cable set for 26.5 GHz PNA or PNA-X
205 CS-24-TxRx-5 5m cable set for 26.5 GHz PNA or PNA-X
401 CS-40-TxRx-1.2
1.2m LF cable set for > 43 GHz PNA or PNA-X
405 CS-40-TxRx-5
5m dual cable set for > 43 GHz PNA or PNA-X
a. TxRx cable sets include IF (2x), LO and RF cables.
Table 8 Available Rx Cable Sets
Keysight Cable
Option
a
VDI
Part Number
Description
501 CS-TST-Rx-1.2
1.2m cable set for controller
505 CS-TST-Rx-5
5m cable set for controller
201 CS-24-Rx-1.2
1.2m cable set for 26.5 GHz PNA or PNA-X
205 CS-24-Rx-5
5m cable set for 26.5 GHz PNA or PNA-X
401 CS-40-Rx-1.2
1.2m LF cable set for > 43 GHz PNA or PNA-X
405 CS-40-Rx-5
5m dual cable set for > 43 GHz PNA or PNA-X
a. Rx cable sets include IF and LO cables.
If ordering a cable set separately, use model number to determine the appropriate set.
Cable Sets
Table 9 Available TxRef Cable Sets
Keysight Cable
Option
a
VDI
Part Number
Description
501
CS-TST-TxRef-1.2 1.2m cable set for controller
505
CS-TST-TxR
ef-5
5m cable set for controller
201 CS-24-TxRef-1.2 1.2m cable set for 26.5 GHz PNA or PNA-X
205 CS-24-TxRef-5 5m cable set for 26.5 GHz PNA or PNA-X
401
CS-40-TxRef-1.2 1.2m LF cable set for > 43 GHz PNA or PNA-X
405
CS-40-TxRef-5 5m dual cable set for > 43 GHz PNA or PNA-X
a. TxRef cable sets include LO/RF and one IF cable.
8
Keysight N5262BW/BT/BR/DRxx Product Note
