Keysight Technologies N5262BW/BT/BR/DRxx Mini VNAX Frequency Extension Modules
Option Information
Refer to the section "Configuring a Module: Ordering a VDI VNAX Mini-Module, N526xBxx"
on page 36 of the Keysight Technologies Banded Millimeter Wave Network Analysis
Technical Overview at https://literature.cdn.keysight.com/litweb/pdf/5992-2177EN.pdf?
id=2870369&cc=US&Ic=eng#page=36
RF/LO Input Power Options
Option 120: Requires +10 dBm at the module input. Recommended for use with
the test set and 1.2m cable set.
Option 500: Requires +2 dBm at the module input. Recommended for direct
connect with 1.2m or 5m cable sets, or the test set with a
5m cable
set.
When using a 1.2m cable set with Option 500, ensure that is set to 2 dBm at
module input. Reduce power on the PNA, or use attenuators.
All models include a 9 Vdc power supply and have compatible options for use with
a PNA/PNA-X or test set controller (see Tables 1- 6, beginning on page 5).
Cable sets are available for purchase for use with the modules. For cable set
options, see page 8.
For information on the controller, refer to the N5261A and N5262A User’s and
Service Guide (N5262-90001) at
http://literature.cdn.keysight.com/litweb/pdf/N5262-90001.pdf?id=1541557
The TxRx and TxRef modules are available with internal micrometer adjustable
(0-30 dB) attenuators. The Rx modules include an external attenuator for high
sensitivity.
For ordering information, reference the Keysight Technologies Banded Millimeter
Wave Network Analysis Technical Overview at
https://literature.cdn.keysight.com/litweb/pdf/5992-2177EN.pdf?
id=2870369&cc=US&lc=eng
4
Keysight N5262BW/BT/BR/DRxx Product Note
