Maintenance
747
Fuse Name Fuse rating Circuit Protected
ECS 15A ECS (Electronic Control Suspension) Unit
S/HEATER
REAR
20A Rear Seat Warmer Control Module
HEATED
MIRROR
10A Air Conditioner Switch, Driver/Passenger Power Outside Mirror
FUEL PUMP 20A Fuel Pump Relay
SPARE1 10A -
SPARE2 15A -
SPARE3 15A -
REAR HEATED 30A Rear Heated Relay
AMP 2 25A AMP (Amplifier) (MOBIS/PREMIUM)
SPARE4 15A -
AMP 1 30A Low DC-DC Converter (AMP (Amplifier))
IG 1 40A IG1/ACC Relay
Rear fuse box panel
