Features of your vehicle
Applying the shackle on the guide rail
• Put the shackle (A) in the position
where the shackle is put in the rail.
• To move the shackle, press the button
(1) and move the shackle along the rail.
• Make sure the shackle is clicked into
place.
• To fix the luggage, pull up the hook (2)
in the middle cargo bay.
• Now you can mount e.g. belt to fix the
luggage in the hook.
• The shackle cannot be used in the
position where the shackle is put in and
out of the rail (3).
❈ The actual luggage room in the vehicle may
differ from the illustration.
Shopping bag holder
OGDE042308
CAUTION
• Do not hang a bag weighing more
than 3 kg (7 lbs.). It may cause
damage to the shopping bag
holder.
• Do not hang the frail objects
when you drive rough road, the
objects may be damaged.
OJD042151
CAUTION
Tensile force : max. 30 kgf. for
1 shackle
