21
6
3 4
5
Connect and tighten the supply hoses by using two
adjustable wrenches (avoid twisting or kinking). Turn
on the angle valve and check for leaks.
Note: Do not remove the net lter that attached
into the connecting end!
From below the sink, Slide rubber washer, metal
washer and mounting bracket onto the thread shank.
Put the rubber O-ring into the bottom gap of
faucets then Insert faucet into faucet hole.
Remove the mounting hardware from the
mounting pipe.
Shut o water suppliers. Remove the old faucet, clean
the mounting surface.
Note: For rst time install, ush the pipes rst by
open the angel valve to run 60s.
Adjust position of faucet body if necessary,
Then tighten the mounting nuts with phillips
screwdriver until snug.
FAUCET INSTALLATION
