Assembly Instructions
6. ATTACH PLAY FIELD SUPPORT BRACE P5 TO THE SIDE PANEL WITH METAL ROD H14,WASHER H2
AND NUT H3 .SEE FIGURE 7-9.
7. ATTACH BALL CATCHER P10 TO SIDE PANEL WITH SCREW H5.SEE FIGURE 10.
8. ATTACH GOAL BOX P9 TO END PANEL WITH SCREW H5.SEE FIGURE 11.
9. CONNECT GOAL BOX P9 AND BALL CATCHER P10 WITH BALL RUNNER P11.SEE FIGURE 12-13.
7
8
9
10
H14
H5
P10
P11
P9
H5
11
12
13
P5
H14
P5
H2
H3
H2
H3
P5
P11
