WIRING SIZE
To make sound electrical connections, the battery cable should be the correct size and
the correct terminals should be crimped or soldered.
WIRES
Alternator output cable (red)
Solar input cable (green)
Output cable (brown)
Common ground (black)
Ignition override (blue)
External LED indicator (brown)
CABLE SIZE
2
8mm (8 B&S)
2
8mm (8 B&S)
2
8mm (8 B&S)
2
8mm (8 B&S)
2
1.5mm
2
1.5mm
Note:
The above recommendation is for cable length up to 8 meters.
For more information or assistance, see installation videos at
kickassproducts.com.au
