6
14. Remove the two 10mm nuts securing the
jack bracket. Fig. 15
15. Remove the jack tool bag.
NOTE: If equipped with the optional
carpeted storage tray as pictured in
Fig. 12, remove at this time. The
storage tray cannot be used in
conjunction with the subwoofer. The
subwoofer by design provides an
optional storage area once it is
installed.
16. Remove the outer rear seat bolt on the
driver’s side. Fig. 16
17. Make cuts in the carpet according to the
measurement in Fig. 17. Only make cuts
where dotted lines are shown.
Fig. 15
1inch
1inch
Fig. 17
Fig. 16
To Next Page
