4
OPERATION
The button layout below will give you a quick overview of the button functionality.
BUTTONS:
1 - Source
2 - Favorites
3 - Menu
4 - Back/Return
5 - Seek/Tune Down
6 - Play/Pause
7 - Seek/Tune Up
8 - Volume Knob
Function: How To:
Power On Hold the Source (1) button for 2 seconds.
Power Off Hold the Source (1) button for 2 seconds.
Volume Up Turn the knob (8) clockwise.
Volume Down Turn the knob (8) counter-clockwise.
Seek Up Press Seek Up (7) once.
Seek Down Press Seek Down (5) once.
Tune Up Hold down Seek Up (7).
Tune Down Hold down Seek Down (5).
Enter/Select Press the Knob (8) inward once.
Pause/Play Press Play/Pause (6) once.
Mute Press Play/Pause (6) once.
Back Press Back (4) once.
1
2
3
8 4 5 6 7
DISPLAY
KMC100 Settings MENU
To enter the Settings Menu : Hold the MENU (3) button for 2 seconds.
Rotate the knob to scroll between menu items and press enter on knob
to select.
Available Settings are:
Day/Night:
The Day/Night feature allows you to change the color scheme from Day
Mode to Night Mode. The unit is defaulted to auto switch when your lights
are turned on. In order for the unit to automatically switch between day
and night modes, the orange illumination wire must be connected. You can
also set the unit to stay in either Day mode or Night mode by rotating the
knob and selecting the desired setting.
Dimmer:
The Dimmer allows you to adjust the brightness of the screen, and buttons.
You can adjust the brightness from 0 to +12.
Low Battery Alert:
The Low Battery Alert setting allows you to turn ON/OFF the Low Battery
Alert. When set to ON, if the unit drops below 10.5V, the unit will display a
visual and audible alert warning that your batteries need charged.
Tuner:
Allows you to change the region for the tuner.
Your available options: USA, EUROPE
To Next Page
