KID Trax KT1309TR - Parts List, Hardware, and Tools

9
Before beginning assembly, check to ensure that the parts listed are
present. Some hardware is aached to the sub assembly.
Hardware
Tools Required
x1
x1
Parts List
# Part name Quanty
1
Front Bumper
1
2 Front Wheel Well 2
3 Mirror Assembly 2
4 Mirror 2
5 Snorkel 1
6 Rear Wheel Well 2
7 Seat 2
8 Steering Wheel 1
9 Roll Bar Assembly 1 2
10 Roll Bar Assembly 2 1
11 Rear Bumper 1
12 Rear Bumper Brace 2
13 Rear Axle 1
14 Gearbox 2
15 Rear Wheel 2
16 Wheel Hubcap 4
17 Front Wheel 2
18 Steering Column 1
19 Wrench 2
20
Charger
1
x4
x6
(included)
(x13 Seat) (x2 Seat) (x6 Seat)
