Kidde Fire Systems
400 Main Street
Ashland, MA 01721
Ph: 508.881.2000
Fax: 508.881.8920
www.kiddefiresystems.com
ARIES is a registered trademark of Kidde-Fenwal, Inc., or its parents, subsidiaries or affiliates.
This literature is provided for informational purposes only. KIDDE-FENWAL, INC. believes this data to be accurate, but it is published and presented without any guarantee
or warranty whatsoever. KIDDE-FENWAL, INC. assumes no responsibility for the product's suitability for a particular application. The fire suppression system design,
installation, maintenance, service and troubleshooting must be performed by trained, authorized Kidde Fire Systems distributors for the product to work correctly.
If you need more information on this product, or if you have a particular problem or question, contact:
KIDDE-FENWAL, INC., Ashland, MA 01721 USA, Telephone: (508) 881-2000.
K-76-236 Rev AC
©2020 Kidde-Fenwal, Inc.
EXPORT INFORMATION (USA)
Jurisdiction: EAR
Classification: EAR99
This document contains technical data subject to the EAR.
SPECIFICATIONS ORDERING INFORMATION
Operating Voltage 16.0 to 28.8 Vdc
(non-resettable)
Standby Current 0.045 A
Output Activation Common Positive individ-
ual-output negative pull
downs
ATM-L Outputs
LED 0.015 A maximum
Audible Appliance 0.015 A maximum
ATM-R Outputs 0.080 A maximum
Total Alarm Current Depends upon output load.
Must be calculated for each
application.
Supervised Power-Limited
Wire Sizes
RS-485
Communications
14 - 18 AWG (Twisted,
Unshielded)
24 Vdc Power 14 - 18 AWG (as required)
LEDs 18 AWG
Functional Switches 18 AWG
Audible Appliance 18 AWG
Power Supply Supervised
Initiating Circuit
14 - 18 AWG
Relays 18 AWG
Part Number Description Weight
76-200004-032 ATM-L Annunciator Driver
Module, 32 independently
programmable LED drivers
2.0 lb.
76-200005-032 ATM-R Relay Driver Module,
32 independently program-
mable relay drivers
2.0 lb.
