2-2
FM-200
®
ECS Series Engineered Fire Suppression Systems
90-FM200M-000 September 2004
2-2.5 Special System Precautions
2-2.5.1 SYSTEMS ACTUATED WITH A MASTER
FM-200 CYLINDER
In systems where a master FM-200 cylinder actuates a pres-
sure operated control head on a slave cylinder, the pres-
sure in the flexible actuation hose line is vented into the
discharge manifold following the system discharge. The
pressure drop in the pilot line allows the pressure operated
control head to automatically reset. However, as a precau-
tion before reinstating the system, ensure that the control
head actuating pin is in the retracted (SET) position.
2-2.5.2 SYSTEMS ACTUATED WITH A PILOT
NITROGEN CYLINDER
In systems where a pilot nitrogen cylinder actuates a pres-
sure operated control head on a slave FM-200 cylinder,
nitrogen pressure is trapped in the pilot manifold when the
system actuates and is not self-venting. Therefore, before
reattaching a pressure operated control head to a recharged
FM-200 cylinder, the following procedure must be performed
to ensure that the pilot manifold is vented and the pressure
operated control heads have returned to the SET position.
1. Vent any remaining pressure from the pilot line and
remove the master control head from the nitrogen
pilot cylinder(s). Reset the master control head and
remove the pressure operated control head(s) from
the slave cylinder(s).
2. Recharge and reinstall the nitrogen pilot cylinders to
the correct charged pressure and reinstall the master
control head.
3. Before installing a pressure operated control head on
an FM-200 cylinder, ensure that the actuator pin is in
the retracted (SET) position.
4. Follow all other procedures and cautions as detailed in
Chapter 6 of this manual.
