4-5
September 2004 90-FM200M-000
FM-200
®
ECS Series Engineered Fire Suppression Systems
Table 4-4. FM-200 Total Flooding Concentration Factors (W/V), Metric
Temp
a
t
(°C)
C
Specific
Vapor
Volume
s
(m
3
/kg)
d
Weight Requirements of Hazard Volume, W/V (kg/m
3
)
b
Design Concentration (% per Volume)
e
6 6.25 7 8 9 10 11 12 13 14 15
0
0.1268 0.5034 0.5258 0.5936 0.6858 0.7800 0.8763 0.9748 1.0755 1.1785 1.2839 1.3918
5
0.1294 0.4932 0.5152 0.5816 0.6719 0.7642 0.8586 0.9550 1.0537 1.1546 1.2579 1.3636
10
0.1320 0.4834 0.5051 0.5700 0.6585 0.7490 0.8414 0.9360 1.0327 1.1316 1.2328 1.3364
15
0.1347 0.4740 0.4949 0.5589 0.6457 0.7344 0.8251 0.9178 1.0126 1.1096 1.2089 1.3105
20
0.1373 0.4650 0.4856 0.5483 0.6335 0.7205 0.8094 0.9004 0.9934 1.0886 1.1859 1.2856
25
0.1399 0.4564 0.4765 0.5382 0.6217 0.7071 0.7944 0.8837 0.9750 1.0684 1.1640 1.2618
30
0.1425 0.4481 0.4678 0.5284 0.6104 0.6943 0.7800 0.8676 0.9573 1.0490 1.1428 1.2388
35
0.1450 0.4401 0.4598 0.5190 0.5996 0.6819 0.7661 0.8522 0.9402 1.0303 1.1224 1.2168
40
0.1476 0.4324 0.4517 0.5099 0.5891 0.6701 0.7528 0.8374 0.9230 1.0124 1.1029 1.1956
45
0.1502 0.4250 0.4439 0.5012 0.5790 0.6586 0.7399 0.8230 0.9000 0.9950 1.0840 1.1751
50
0.1527 0.4180 0.4366 0.4929 0.5694 0.6476 0.7276 0.8093 0.8929 0.9784 1.0660 1.1555
55
0.1553 0.4111 0.4293 0.4847 0.5600 0.6369 0.7156 0.7960 0.8782 0.9623 1.0484 1.1365
60
0.1578 0.4045 0.4225 0.4770 0.5510 0.6267 0.7041 0.7821 0.8410 0.9469 1.0316 1.1183
65
0.1604 0.3980 0.4156 0.4694 0.5412 0.6167 0.6929 0.7707 0.8504 0.9318 1.0152 1.1005
70
0.1629 0.3919 0.4092 0.4621 0.5338 0.6072 0.6821 0.7588 0.8371 0.9173 0.9994 1.0834
75
0.1654 0.3859 0.4031 0.4550 0.5257 0.5979 0.6717 0.7471 0.8243 0.9033 0.9841 1.0668
80
0.1679 0.3801 0.3971 0.4482 0.5178 0.5890 0.6617 0.7360 0.8120 0.8898 0.9694 1.0509
85
0.1704 0.3745 0.3912 0.4416 0.5102 0.5803 0.6519 0.7251 0.800 0.8767 0.9551 1.0354
90
0.1730 0.3690 0.3854 0.4351 0.5027 0.5717 0.6423 0.7145 0.7883 0.8638 0.9411 1.0202
a
The manufacturers listing specifies the temperature range for operation.
b
W/V [agent weight requirements (kg/m
3
)] = kilograms of agent per cubic meter of protected volume to produce
indicated concentration at temperature specified.
W = (V/s) X [c/(100-c)]
c
t [temperature (°C)] = the design temperature in the hazard area
d
s [specific volume (m
3
/kg)] = specific volume of superheated FM-200 vapor can be approximated by the formula:
s = 0.1269 + 0.0005 t
where t = temperature (°C)
e
C [concentration (%)] = volumetric concentration of FM-200 in air at the temperature indicated.
