Kidde Fire Systems FM-200 ECS Series User Manual

5-490-FM200M-000 September 2004
FM-200
®
ECS Series Engineered Fire Suppression Systems
0.0
5.0
10.0
15.0
20.0
25.0
50 75 100 125
FM-200 Weight (lb.)
Flexible Tape Reading (inches)
130°F
100°F
70°F
30°F
Figure 5-2. Calibration Chart 125# Cylinder
12.0
14.0
16.0
18.0
20.0
22.0
24.0
26.0
28.0
30.0
125 150
175
200
FM-200 Weight (lb.)
Flexible Tape Reading (inches)
40°F
70°F
100°F
130°F
Figure 5-3. Calibration Chart for
Old 200# Cylinder
5.0
10.0
15.0
20.0
25.0
30.0
35.0
75 100 125 150 175 200
FM-200 Weight (lb.)
Flexible Tape Reading (Inches)
130°F
100°F
70°F
30°F
Figure 5-4. Calibration Chart for a New 200# Cylinder
(New Design Ellipsoidal Head Manufactured After 3/98)
0.0
5.0
10.0
15.0
20.0
25.0
30.0
150 175 200 225 250 275 300 325 350
FM-200 Weight (lb.)
Flexible Tape Reading (Inches)
30°F
70°F
100°F
130°F
Figure 5-5. Calibration Chart for 350# Cylinder
