FM-200
®
ECS Series Engineered Fire Suppression Systems
September 2004 90-FM200M-000
NOMENCLATURE PART NUMBER
Table 7-1.Parts List
CHAPTER 7
PARTS LIST
CYLINDER/VALVE ASSEMBLIES
Vertical Mount Only
10 lb. STD 90-100010-001
20 lb. STD 90-100020-001
40 lb. STD 90-100040-001
70 lb. STD 90-100070-001
125 lb. STD 90-100125-001
125 lb. W/LLI 90-100121-001
200 lb. STD Old Style Hemispherical Head before 3/98 90-100200-001
200 lb. W/LLI Old Style Hemispherical Head before 3/98 90-100201-001
200 lb. STD New Style Ellipsoidal Head after 3/98 90-100200-101
200 lb. W/LLI New Style Ellipsoidal Head after 3/98 90-100201-101
350 lb. STD 90-100350-001
350 lb. W/LLI 90-100351-001
600 lb. STD (old style supplied before 9/01) 90-100600-001
600 lb. W/LLI (old style supplied before 9/01) 90-100601-001
600 lb. STD (new style supplied after 9/01) 90-100600-100
600 lb. W/LLI (new style supplied after 9/01) 90-100601-100
900 lb. STD 90-100900-001
900 lb. W/LLI 90-100901-001
(STD = Standard Cylinder Assembly, W/LLI = Cylinder with liquid level indicator)
FLEXIBLE DISCHARGE HOSES
10-125 lb. Cylinders 283898
200-350 lb. Cylinders 283899
600 lb. Cylinders (old style supplied before 9/01) 283900
600 lb. Cylinders (new style after 9/01) 06-118225-001
900 lb. Cylinders 06-118225-001
7-1 INTRODUCTION AND PARTS LIST
The table below, and on the following pages, provides a
complete list of FM-200
®
parts and associated system
equipment. FM-200 equipment can be ordered as com-
plete assemblies or as individual items. In most situations,
when ordering a system, it will be easier and more cost
effective to order by assembly part numbers.
