5. Using Your Digital Alarm(4MDCO) – what the signals mean
LEDs LCD Sounder Unit Status Acon
Normal Operaon
Red
0
None Normal Operaon None
Amber
Alarm
Red Flashing
4 loud beeps/pause/4
loud beeps- repeated
CO detected See secon
Amber
Interconnected CO
alarm detects CO
Red Flashing
CO
4 loud beeps/pause/4
loud beeps- repeated
Interconnected CO alarm
detects CO
See secon
Amber
Interconnected Heat/Smoke
alarm detects hazard
Red Flashing
Fix fire
3 loud beeps/pause/3
loud beeps- repeated
Smoke or heat has been
detected from an intercon-
nected smoke or heat alarm
EVACUATE THE
PREMISES ACCORDING
TO YOUR ESCAPE PLAN
Amber
Error condion -1
Red Flashing every 30 secs
Err Chirp/30 secs Unit has failed Replace
Amber Flashing every 30 secs
Error condion -2
Red ON
Constant loud sound
Unit microprocessor has
failed
Replace
Amber
End of Life
Red Flashing
End Chirp twice every
30 seconds
The unit has reached the
end of its life
Replace
Amber Flashing twice every 30 secs
Charging the baery
back up
Red
Lb Flashes NONE
Baery backup is charging (unit
is monitoring for CO)
Nothing
Amber Flashing every 15 secs
Low baery
Red Flashing every 15 secs
Lb Chirp / 15 secs Back up baery is
discharged
Ensure switch is On at
the rear of the unit - if it
persists contact Kidde
Amber Flashing every 15 secs
(Lb Flashes)
Displays CO ppm
( 30-999)
NOTE: If AC mains is connected and acve, the Green LED will be on connuous. If Green LED is not on, see Secon 6.
2512-7220-03_v4:_ 2016.1.14 2:04 PM Page 9

Kidde 4MCO Specifications

General

Type	Carbon Monoxide Alarm
Sensor Type	Electrochemical
Test/Reset Button	Yes
Alarm Sound	85 dB at 10 feet
Power Source	AC Plug-in
Battery Backup	Yes
Mounting	Wall
Certifications	UL 2034
LED Indicators	Yes (Power, Alarm)
