2.After selecting the proper smoke alarm location as described in
Section 1, attach the mounting bracket to the ceiling as shown
in figure 3. For wall mounting see figure 4. Place the mounting
plate on the wall; be sure the “A” line is horizontal (parallel to
the floor). Use the screws and anchors provided to secure the
mounting bracket (use 3/16” drill bit for anchors).
3.This alarm has a battery permanently sealed inside the alarm no
battery installation is necessary.
ACTIVATING THE ALARM
This model is equipped with a feature that automatically
activates the alarm when the alarm is mounted to the
mounting bracket for the first time. Once activated, the
battery will supply power to the alarm for the life of the
alarm (10 years). Be sure that the mounting bracket is
mounted correctly before installing the alarm on the mount-
ing bracket.
1.To activate the alarm, install the alarm on the mounting bracket
(figure 6) and rotate the alarm clockwise (as indicated on the
alarm cover) until the alarm ratchets into place (the ratcheting
function allows for aesthetic alignment). NOTE: The alarm will
mount to the bracket in four (4) positions (every 90 degrees).
The alarm is now activated!
2.After installation/activation, test your alarm by depressing and
holding down the test button for a minimum of 5 seconds (or
until the alarm sounds). This should sound the alarm. CAU-
TION: Due to the loudness (85 decibels) of the alarm,
always stand an arms length away from the unit when
testing.
TAMPER RESIST FEATURE
Smoke Alarm Tamper Resist Feature
This alarm is equipped with a tamper resist feature that helps pre-
vent someone from removing the unit from the mounting bracket.
When activated, it can be very effective in preventing smoke alarm
removal or tampering.
Activate the smoke alarm tamper resist feature by breaking off the
four posts in the square holes in the mounting bracket (see figure
0910-7225-00(21008311A)_EN.qxd:_ 2011.3.22 10:05 AM Pag

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kidde i9010 and is the answer not in the manual?

Kidde i9010 Specifications

General IconGeneral
Detector typeCarbon monoxide detector
Product colorWhite
Alarm decibels85 dB
InterconnectableNo
Connectivity technology-
Power sourceBattery
Weight and Dimensions IconWeight and Dimensions
Depth25.4 mm
Diameter142.24 mm
