33
A. In order to loosen the harness straps, push the central adjusting button which is
located in the center part of the safety seat (see Product Components, element 8).
While pushing the central adjusting button, pull the shoulder straps in order to extend
their length.
B. Push the red button on the central harness buckle to unfasten the harness. Adjust the
length in a way that both, the right and the left shoulder strap are the same length
C. The safety seat has specifi cally designed for this purpose belt loops which are located
halfway through the outer surface of the backrest. The shoulder strap buckles can be
hooked on these belt loops to facilitate placing the child in the safety seat.
D. While fastening the harness, make sure that the hip strap and the shoulder straps
are fi xed adequately tight against the body of the child. Too much freedom or too little
freedom of the harness against the body of the child could result in danger being
posed to the child.
E. Attach the shoulder strap buckles together before they are connected by the central
adjusting button. When connecting all of the straps together you should hear a “Click”
sound signifying that the harness has been fastened properly.
F. While pushing the central adjusting button, gently pull the strap right next to the
button. Remember that the harness has to be in adequately close proximity against
the body of the child, however, not in such close proximity that would cause any
type of discomfort to the child. For this reason, it is not recommended for the child to
wear thick clothes and many layers of clothing as the distance between the harness
system and the body of the child could be distorted.
A. In order to loosen the harness straps, push the central adjusting button which is
located in the center part of the safety seat beneath the seat cover (see Product
Components, element 8). While pushing the central adjusting button, pull the shoulder
straps of the 5-point harness system in order to extend their length.
B. Unfasten the harness straps from the hook connecting 5-point harness straps (see
Product Components, element 19) and pull them out. The next step is unfastening
the harness strap buckles which are located on both harness straps, slide them down
all the way until the end of the straps. Next, pulling one of the sides, extend the length
of the strap.
C. Remove the seat cover on the sides of the safety seat; place and pull the shoulder
straps beneath it so that they are in close proximity to the harness adjustment opening.
Next, pull these shoulder straps along and through the opening in the backrest and
connect them with the hook connecting 5-point harness straps. Place the excess of
the harness straps in the carvings of the safety seat beneath the seat cover.
D. In order to separate the central harness buckle from the safety seat, twist the buckle
strap by 90° and slowly pull along the guideway. Be careful about whether the hook,
which is located below the seat, is placed properly in a way that it can be pulled
through the specifi cally for this purpose designed opening.
E. Put the seat covers back on and make sure that none of the elements of the harness
sticks out and the seat cover is fi xed tightly against the frame of the safety seat.
5-POINT HARNESS SYSTEM FASTENING AND ADJUSTMENT
UNFASTENING THE 5-POINT HARNESS SYSTEM
2
3
