35
A. Find the ISOFIX attachment points located between the backrest of the vehicle
seat and the base of the vehicle seat. After fi nding them, attach the ISOFIX Guide
sleeves (see Product Components, element 22).
B. Press the button releasing the lock and extend the ISOFIX Attachments until they
achieve their full reach.
ISOFIX ATTACHMENT
8
A. Press and pull the headrest height adjustment handle (see the Product Components,
element 12).
B. The headrest can be moved upwards and downwards. The headrest height
adjustment handle should be released, when the desired height of the headrest for
child’s comfort and safety is achieved.
C. Make sure that the vehicle seat belts are located at a correct height
D. The correct height of the vehicle seat belt is achieved when the guideway for the
seat belt is located slightly above the shoulder of the child
ADJUSTING HEADREST HEIGHT
ATTACHMENT TYPES
6
7
