36
ATTENTION: Make sure that the Top Tether strap is not twisted.
ATTENTION: Make sure that the Top Tether hook lock is pointing downwards, next,
connect it to the vehicle attachment point– the Tether anchor
A. The anchor point is located on the shelf next to the rear quarter glasses of the vehicle.
B. The anchor point is located at the bottom of the trunk of the vehicle.
C. The anchor point is located underneath the vehicle rear seat, there is a possibility that
lying down the seats fl at could be needed in order to fi nd the anchor.
D. The anchor point is located at the back of the vehicle rear seat (on the side of the trunk)
TOP TETHER SYSTEM
9
C. Press the ISOFIX Attachment into the FIX points, a loud “Click” sound will signal
that the lock is active. An additional element indicating about the lock being active
is a green symbol located on the ISOFIX button.
ATTENTION: Check on both sides of the safety seat whether the ISOFIX button
indicates that the lock is active.
D. Grab the entire safety seat fi rmly and make sure that it is properly attached
ATTENTION: If the safety seat is not pressing against the vehicle seat or if the space
between the two is too big and the ISOFIX Attachments are extended, repeat the above
mentioned steps and attach the ISOFIX system again.
REARWARD TO THE DIRECTION IN WHICH THE VEHICLE IS MOVING –
ISOFIX ATTACHMENT + TOP TETHER
A. The base adjustment should be in the forward position - this means that the base
position will be located directly under the seat.
B. Rotate the safety seat rearward to the direction in which the vehicle is moving.
For Group 0+ adjust the inclination to position 4. Next, pull out the vehicle seat belt.
ATTACHMENT OF SAFETY SEAT FOR GROUP 0, I
10
