38
A. Rotate the safety seat rearward to the direction in which the vehicle is moving. For
Group 0 adjust the inclination to position 4. Next, pull out the vehicle seat belt.
B. Pull the shoulder belt through the belt guide for Group 0 – rearward facing (see (01)
Product Components Overview, element 13). Next, remove the reduction cushion
and pull the hip belt along the front of the safety seat (see Product Components,
element 23).
ATTENTION: If the child weighs less than 13 kg, the reduction cushion needs to be
placed back to the initial position on the safety seat. Next, fasten the vehicle seat belt.
The “Click” sound will signify that the vehicle seat belt has been fastened.
C. Press the safety seat against the vehicle seat simultaneously pulling the shoulder
belt in the retracting direction as if it were to be stowed. This must be done in order
to ensure tight positioning of the safety seat against the vehicle seat. Grab the
entire safety seat fi rmly and make sure that it is stably attached, also make sure
that the safety belt withstands application of force.
FORWARD TO THE DIRECTION IN WHICH THE VEHICLE IS MOVING –
ISOFIX ATTACHMENT + 3-POINT SEAT BELT
ATTACHMENT OF THE SAFETY SEAT FOR GROUP I
12
