PART NO. IB021853
Apr. 2011
Installation and
Preparation
Basic Functions
Advanced Operations
Sequences
External Control and
Master-Slave Control
Remote Control
Maintenance
App
User’s Manual
PLZ-4WH Series Electronic Load
1
2
3
4
5
6
7
Specifications
8
PLZ164WH
PLZ334WH
PLZ1004WH

Table of Contents

Other manuals for Kikusui PLZ164WH

Preview: Setup Guide
Setup Guide10 pages

Questions and Answers

  • J
    Jo HallAug 9, 2025
    Why is the ALARM activated on my Kikusui Measuring Instruments?
    • B
      Bobby HoustonAug 9, 2025
      The ALARM may activate on your Kikusui Measuring Instruments due to: * Overheat protection tripped. In this case, immediately stop using the instrument and request repairs. * Overheat protection tripped because of a clogged dust filter. Ensure there is at least 20 cm of space between the air outlet and any wall, and keep objects at least 20 cm away. Clean the dust filter. * The OCP or OPP setting is too small. Reset the OCP or OPP value in the setup screen.
  • C
    castillopaulaAug 14, 2025
    Why is the input current unstable or oscillating on my Kikusui Measuring Instruments?
    • R
      ronnie20Aug 14, 2025
      Unstable or oscillating input current on your Kikusui PLZ-4WH Measuring Instruments can be caused by: * Low supply voltage. Use the PLZ-4WH within the correct input supply voltage range. * An internal or external error. Check the alarm type and apply the appropriate fix. Other solutions include twisting the wires and changing the response (transient response) using the menu setup. If the issue persists, immediately stop using the instrument and request repairs.
  • B
    Brian EricksonAug 19, 2025
    How to fix a Kikusui Measuring Instruments when nothing appears on the display?
    • R
      Rachel SmithAug 19, 2025
      If nothing appears on the display of your Kikusui Measuring Instruments when you turn on the power, check the following: * Ensure the power cord is not broken and is securely connected to the AC INPUT connector on the rear panel. If this doesn't resolve the issue, remove the power cord plug from the outlet, immediately stop using the instrument, and request repairs.
  • H
    Harold BarrettAug 25, 2025
    What to do if the keys do not work on Kikusui Measuring Instruments?
    • S
      Sarah ClarkAug 25, 2025
      If the keys on your Kikusui Measuring Instruments are not working, it could be because the key lock is enabled. Release the key lock. If this doesn't solve the problem, immediately stop using the instrument and request repairs.
  • R
    Rachel Drake MDAug 29, 2025
    Why the load cannot be turned on on my Kikusui Measuring Instruments?
    • R
      Rodney DavidsonAug 30, 2025
      The load on your Kikusui Measuring Instruments might not turn on because: * The sequence operation is in progress. Wait for it to finish or abort it by pressing STOP. * The load on/off logic (Load ON IN) is set to low. In the menu, select “Configuration” and set “Load ON INput” to “HIGH.”
  • T
    Trevor ColeSep 3, 2025
    How to fix a dark display on Kikusui Measuring Instruments?
    • M
      mark02Sep 3, 2025
      A dark display on your Kikusui Measuring Instruments can be due to: * Low supply voltage. Use the PLZ-4WH within the specified input supply voltage range. * Incorrect contrast adjustment. Adjust the contrast.

Kikusui PLZ164WH Specifications

General IconGeneral
ModelPLZ164WH
TypeElectronic Load
Number of Channels1
Max Voltage150 V
Control MethodConstant Current, Constant Resistance, Constant Voltage, Constant Power
Operating Temperature0 to 40 °C
Storage Temperature-20 to 70 °C
InterfaceUSB, GPIB, RS-232C
Cooling MethodForced Air
