4
back before inserting
new meter disc
meter disc
Procedure
6. Install By-pass
Use of an external 3-valve by-pass or equivalent is
recommended.
7. Connect Softener
Connect softener to main plumbing via by-pass.
Connect softener to main plumbing via by-pass.
Do not solder brass adapters while they are inserted in
the control module.
Take care during the installation process to assure that
solder and flux do not come in contact with:
media tanks
control module
E-clips
related plastic components
8. Set Meter Disc
Set number of gallons between regenerations based on your system size and inlet water quality (see step 10).
Remove cap and
3
7
Tighten cap screws (8)
in order shown
4
Gently turn disc clockwise
until pawls fall in place
To Next Page
