Page 2
If your roof is 4-1/2” to 8” thick
you will need to install KING extension #21850.
If using the extension, install it now,
BEFORE INSTALLING BASE MOUNT ON ROOF.
• Remove the existing adjustable connector from the upper
connector located in the base mount.
• Extension only ts onto upper connector one way. Line up
as shown at right and engage the extension onto the upper
connector.
• Leave extension sticking out of base mount more than the
thickness of the roof.
ROOFS 4 1/2” to 8” THICK ONLY!
Roofs thinner than 4 1/2” go to next page.
EXTENSION INSTALLATION
CONTENTS
IMPORTANT!
For roofs 4-1/2” to 8”
thick, install
KING extension #21850.
IMPORTANT!
You must install
the included
wall mount
power inserter
to operate the
KING Jack
antenna
(see page 5).
To Next Page
