KingCraft PCSD180T - List of Main Parts; Technical Specifications

FUNCTIONAL DESCRIPTION
Figure-4
Figure-5
3
LIST OF MAIN PARTS
1) Battery pack 6) Nut
2) Upper guard 7) Saw blade
3) Base 8) Switch lock
4) Flange
5) Lower guard
Figure 6
9) ON/OFF switch
CLAMP NUT
TECHNICAL SPECIFICATIONS:
Description PCSD180T
Rating Voltage 18Volts
Nominal power 200W
No-load speed 2500min
Saw blade
Ø6.49×Ø 0.39inch
Cutting depth at 90˚ 0-2.00inch
Cutting depth at 45˚ 0-1.50inch
Weight 7.49pound
No-load noise 85dB
4
