Getting Started . . .
Your machine
1. Power unit
2. Recoil starter handle
3. Spark plug connector
4. Choke
5. Air lter case
6. Primer
7. Fuel tank cap
8. Fuel tank
9. Ventilation openings
10.
Harness with quick-release mechanism
11. Upper drive shaft tube
12. Front handle
13. Barrier bar
14. Shaft clamp
15. Locking nut
16. Lock pin
17. Bottom drive shaft tube
18. Gear head
19. Throttle trigger
20. Stop switch
21. Throttle trigger lockout
22. Cutting-attachment guard
23. Backing ange
24. Cutting blade (with transport cover)
25. Locking ange
26. Securing nut
27. Trimming guard
28. String trimmer head
29. Rear handle
30. Spindle
31. Cutting line
32. Cutting line cutter
Accessories
33
34 35
36 37
33. Multi-tool I (Cross-head screwdriver/
socket wrench)
34. Multi-tool II (Torx screwdriver/round rod)
35. Hex key 5 mm
36. Hex key 4 mm
37. Fuel mixing bottle
Unpacking
1. Unpack all parts and lay them on a at, stable surface.
2. Remove all packing materials and protective shipping materials, if applicable.
3. Make sure the delivery contents are complete and free of any damage. If you nd
that parts are missing or show damage do not use the machine and contact your
dealer. Using an incomplete or damaged machine represents a hazard to operators
and property.
4.
Ensure that you have all the accessories and tools needed for assembly and operation.
This also includes suitable personal protective equipment.
