26
FPPBC25-6
In more detail . . .
Harness
NOTE: The harness improves working movement and enables the operator
to manage the job in a safer way and takes the strain away from the body.
Always wear the harness when working with the machine. Always turn the machine
off and wait until the cutting attachment stops completely before taking off the
harness.
1. Unclip the harness (10) from the upper drive shaft tube (11).
2. Place the harness (10) over your left shoulder crossing the chest and back. The quick-
release must be located at the right hip (Fig. 13).
3. Clip the harness (10) to the upper shaft tube (11).
4. Adjust the length of the harness (10) so that the weight of the machine is balanced and
the cutting attachment is approximately 10-15 cm above the ground.
17
In
EN
the petrol brush cutter and trimmer to
17
In
EN
the petrol brush cutter and trimmer to
17
In
EN
the petrol brush cutter and trimmer to
10
10
Red tag
Quick release
13
14
WARNING! In the event of an emergency, pull the red tag of the quick-release
upwards to release the machine from the harness (Fig. 14).
Barrier bar
The barrier bar (13) is for restricting backward movement of the machine. Always assemble
the front handle (12) with the barrier bar (13) to the machine (Fig. 15).
Throttle trigger lockout
The throttle trigger lockout (21) prevents unintentional start of the throttle trigger (19). The
throttle trigger can only be activated if the throttle trigger lockout is pressed (Fig. 16).
Machine function
