Kingfisher MCB1018HVM - EN Machine description

3
EN Machine description
EN
1. Start lever (x2)
2. Safety lock-off button
3. Grip handle
4. Cord strain-relief hook
5. Power cord with plug
6. Upper handle
7. Lower handle
8. Wing nut (x2)
9. Washer (x2)
10. Collect/mulch mode selector
11. Unlock button
12. Mulch ap
13. Collection chute
14. Grass catcher
15. Screw (x2)
16. Cutting deck
17. Cutting blade
18. Wheels (x2)
19. Grass catcher lid
20. Spanner (scrapper)
21. Bolt (x2)
22. Cord clips (x3)
23. Motor cord
1
2 3
6
8
7
20
9
15
16
18
19
14
22
23
4
1011
12
13
17
5
21
