Kingrex UC192 - Specification; USB Interface; SPDIF Interface

8
D. Specification:
 USB interface :
-USB 2.0 High/Full Speed compliant
-USB Audio Device Class Specification v1.0/2.0 Compliant
-- Adaptive Clock Generator for Audio Streaming Synchronization
- Supports CRC Error Correction for Playback Data.
IIS audio interface:
- Sample Rates Supported:44.1Khz, 48Khz, 88.2Khz, 96Khz, 176.4Khz, &192Khz
- 16,20,24 bit & 32bit 2 Channel
 SPDIF Interface:
With two type output connector:
Coaxial & AES/EBU
-1 Stereo SPDIF output through Integrated IEC958 Line Driver
-16,20, 24bit Mono/2 Channel
-Sample rates support : 44.1Khz, 48Khz, 88.2Khz, 96Khz. & 192K.
S/PDIF output voltage: 2.5Vpp
AES/EBU output voltage: 2.5 Vpp
Power demand : 7.5V DC
Power consumption : 200mA @7.5V
