Kinroad XT50-5 - Adjustment of Rear Brake

19
Adjustmen
t
o
f
Rea
r
Brake
ƾThe vehicle should be supported by the main stand for check.
(1) The rear brake pedal has a free operating movement of 20-
30mm as shown in the figure on the right side.
(2) To make adjustment, turn the rear brake adjust ing nut clo
ckwise to reduce snd counter clock wise to increase the free ope
rating movement of the brake pedal.
Adjustmen
t
o
f
Chain
1.When regulation is needed. Ioosen the rear axle nut
2.Turn the chail adjust ing nuts
on the left and right sides to adjust the tension of the chain and to align
the marking of the chain adjuster with the engraved lines in the similar
position, on both sides.
3.Tighten the lock nut and rear axke nut by a torque of 35-50Nm.
4. Repetitively check the tension of the chain.
5.When the rear wheel is changed in position and the chain adjusted,
the free operating movement of the rear brake pedal will be affected,
which, therefore, should be checked thereafter and also regulated if
necessary
