10 -29PERIODIC SERVICE
1. Head lights and rear combination lights:
Take the bulb out of the light body and replace with a new one.
2. Other lights:
Detach the lens and replace the bulb.
REPLACING LIGHT BULB
PROTECTED CIRCUIT
CapacityLight
35W / 35W
55W / 60W
55W / 60W
5W
21W
5W
21W / 5W
21W
21W
1.7W,3.4W(Charge Lamp)
Head Lights(AU)
Head Lights(EU)
Head Lights(EN)
Tail Lights(AU)
Stop Lights(AU)
Front Position Lamps(EU)
Stop Lights/Rear Position(EU)
Turn signal Lights
Work Light
Instrument panel Light
1
2
3
4
5
6
7
8
9
10
No. Capacity Protected circuit
1
2
3
4
5
6
7
8
9
Heater Control/
Timer Relay
Customer Use
Work Light
Head Lights/Tail Light
Comi Meter
Engine Stop Solenoid
Stop Lights
Turn Signal Lamp/Horn
Fuse Holder
10A
10A
10A
15A
5A
25A
10A
10A
25A
