5
-5
OPERATION
051O502C
2. MAKE SURE THE FUEL COCK IS
IN THE OPEN POSITION.
(1) Fuel Cock
(A) Close (B) Open
3. PLACE THE PTO CLUTCH LEVER
IN "OFF" POSITION.
4. PLACE THE SPEED CONTROL
PEDAL IN "NEUTRAL" POSITION
(HST TYPE).
5. MAIN SHIFT LEVER TO NEUTRAL
POSITION (MANUAL TYPE).
6. PLACE THE RANGE GEAR
SHIFT LEVER (HI-LO) IN "NEU-
TRAL" POSITION.
NOTE
The speed control pedal automati-
cally return to neutral when the
operator's foot is released from the
pedal.
(1) P.T.O Clutch Lever
(2) Speed Control Pedal
(3) Range Gear Shift Lever (Hi-Lo)
“ON”
“OFF”
“HI” High
(N)
“NEUTRAL POSITION”
“Lo” Low
051O503C
To Next Page
