5
-14 CK22
(1) HAZARD LIGHT SWITCH
When hazard light switch is pushed
"ON", the hazard lights flash along with
the indicator on the instrument panel.
Push the switch to "OFF" to turn flash-
ers "OFF".
2. SELECTING LIGHT SWITCH PO-
SITIONS
(1) Hazard / Turn Signal Indicator
(2) Turn Signal Light Switch
(3) Hazard Light Switch
051O518C051O517C
(2) TRAVEL/HEIGHT ADJUSTMENT
Pull out the position adjust lever and
slide the seat backward or forward, as
required.
(1) Seat Belt
Adjust the seat belt for proper fit and
connect to the buckle. The seat belt is
an auto-locking retractable type.
(3) SEAT BELT
After adjusting the operator’s
seat, be sure to check that the
seat is properly locked.
IMPORTANT
To avoid personal injury:
Always use your seat belt when
the ROPS is installed.
Do not use the seat belt if your
tractor is not equipped with a
ROPS or when it is removed.
!!
!!
!
CAUTION
(2) TURN SIGNAL LIGHT SWITCH
To indicate a right turn, push forward.
To indicate a left turn, push rearward.
To Next Page
