10
-10 CK22
(1) HST Oil Filter
HST Type
051OA14C
4. Tighten the filter firmly until it con-
tacts the mounting surface. Then
tighten the filter, by hand, an addi-
tional half turn only.
5. After the new filter is in place, fill the
transmission up with oil to the upper
line of the oil gauge.
6. After running the engine for a few
minutes, stop it and check the oil
level again, add oil to the prescribed
level.
(1) Gauge (2) Oil Filler Plug
(A) Oil level is acceptable within this range
051OA15C
REPLACING HYDRAULIC OIL FILTER
& TRANSMISSION OIL FILTER
1. Place the oil pan under the hydrau-
lic oil filter.
2. Remove the oil filter.
3. Place a film of clean transmission
fluid to the rubber seal of the new
filter.
To avoid personal injury:
Be sure to stop the engine be-
fore changing oil filter cartridge.
!!
!!
!
CAUTION
(1) Hydraulic Oil Filter
051OA13C
MANUAL Type
HST Type
To Next Page
