6-10 DK451/501/551
INITIAL 50 HOURS
CHANGING ENGINE OIL
(1) Oil Inlet (2) Oil Gauge
(A) Oil level is acceptable within this range
(1) Drain Plug
A12O608A
A12O609A
1. To drain the used oil, remove the drain
plug at the bottom of the engine and
drain the oil completely into the oil pan.
All the used oil can be drained out
easily when the engine is still warm.
2. After draining reinstall the drain plug.
3. Fill with the new oil up to the upper
notch on the dipstick.
CAUTION
To avoid personal injury:
Be sure to stop the engine be-
fore changing the oil.
Allow engine to cool down suffici-
ently, oil can be hot and can burn.
Oil capacity with filter
8.0 (2.11 U.S.gal.)
9.7
(2.56 U.S.gal.)
DK451
DK501
DK551
Model
A12O610A
(1) Oil Filter Cartridge
IMPORTANT
To prevent serious damage to the
engine, use only a KIOTI genuine
filter.
REPLACING ENGINE OIL FILTER
To Next Page
