DESCRIPTION OF OPERATING SYSTEM 4-11
A12O417A
HYDRAULIC SYSTEM WARNING LAMP
This lamp lights up yellow when certain
problems occur in hydraulic system.
This lamp lights up when the pressure in
hydraulic system drops down below a
specified value due to high oil tempera-
ture (approx. 60 + 5°C) or blocked oil fil-
ter carefully check the hydraulic system.
A12O419A
The battery charge lamp will glow red
when the main switch is turned on and
should go out as engine starts. If the lamp
continues to glow above idle speeds, the
battery is being discharged, indicating the
electrical system should be checked.
BATTERY CHARGE WARNING LAMP
The oil pressure lamp will glow red when
the key switch is turned on. This indi-
cates the light and electrical wiring are
functioning properly. The light should go
out after engine starts. If light remains
on, stop engine and inspect cause.
ENGINE OIL PRESSURE WARNING
LAMP
A12O418A
