DESCRIPTION OF OPERATING SYSTEM 4-27
A12O445A A12O446A A12O447A
EXTERNAL NAME OF THE CABIN
(1) Working Lamp(Front) (3) Rear View Mirror
(2) Working Lamp(Rear) (4) Wiper
1. The cabin is designed for comfort and
convenience and is made of steel frame.
2. It always provides you wide-angle
view by using very wide window, exter-
nal rear view mirror on the left and right
side, and window-shield wiper in case
of rain.
3. It is possible for you to work slowly
and conveniently using air conditioning
and heating system.
4. With doors on both sides, entry on ei-
ther side is possible.
REAR WINDOW
(1) Handle Of Rear Window
(2) Button
If you lightly push rear window while
depressing the button on the handle, the
rear window will automatically open.
WARNING
Sometimes, it is impossible for
you to open and close the window
because of the detachment, please
make sure of the position of the
attachment when opening and
closing it.
Do not drive the tractor at full
speed or on the road with sharp
curves with the window open.
ENTRANCE ON EITHER SIDE
(1) Handle Of Entrance
(2) Button
Pressing the button of the handle will
open the door, and then it will be fixed
after opening to some extent.
The cabin can be locked and unlocked
by inserting the key into the lock and
turning.
