Kioti KL120 - Connecting Hydraulic Hoses

14-4 KL120
Install Attach Fitting Flange.
W/Quick Coupler (Male)
1 Attach Fitting Flange
W/Quick Coupler(Male) -1SET
2 Hex Head Bolt
M10X1.5PX25L -2EA
Spring washer ø 10 - 2EA
120OE04A 120OE05A
Install the hydraulic hose matching color code rings as shown on
the diagram below.
